INTEGRATED SOLAR LED STREET LIGHT (ALL IN ONE) 12W
The NES-LIA-12 Integrated Solar LED Street Light (All In One) is an innovative solution designed for efficient, sustainable, and reliable outdoor illumination. This all-in-one unit combines the solar panel, battery, and LED light source in a single, compact system. With a powerful 12W LED output and an impressive lumen efficacy of ≥120 Lm/W, it provides excellent lighting for roads, highways, gardens, parks, and other public spaces. The integrated 12.8V, 12Ah battery ensures long-lasting performance, storing solar energy harnessed by the 12V 40W solar panel. The system is designed with high driver efficiency (>85%) to minimize energy loss, making it a cost-effective and reliable lighting solution. With an IP65 rating, this light is fully protected against dust and water, making it ideal for installation in harsh outdoor conditions. The NES-LIA-12 is perfect for a variety of applications including security lighting, airport runways, and border area lighting.
Highlights
- Power
- 12W
- Output Lumens
- ≥120 Lm/W
- Battery Size
- 12.8V, 12Ah
- CRI
- >70
- Reply within 1 business day
- Bulk & tender pricing
- Certificates on request
Engineered for performance
-
Lifespan
A – 50,000 L90 B10 B – 100,000 L90 B10
-
Low Flicker
Designed for stable, comfortable illumination with low flicker performance.
-
Operating Temperature
-10°C to +55°C
-
Dimming
On request: DALI, 0–10V, 1–10V
Product details
Built for the job, down to the detail.
Technical specifications
- Output Lumens
- ≥120 Lm/W
- Battery Size
- 12.8V, 12Ah
- CRI
- >70
- Solar Panel
- 12V 40W
Need photometric files, drawings or test reports? Request the full datasheet and we’ll send it with your quotation.
